LOLLIPOP DEPOSITING MAKING MACHINE from China manufacturer - NANTONG TWINKLE MACHINERY EQUIPMENT CO.,LTD

Price:	1000.0~100000.0 USD
Payment Terms:	T/T,L/C;CASH
Place of Origin:	Jiangsu, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: TK-528

Production Capacity: 10 SET PER MONTH

Delivery Date: 45 DAYS AFTER GET DEPOSIT

Means of Transport: Ocean;BY SEA

Packing: WOODEN PACKING

FOOD PROCESSING MACHINERY: LOLLIPOP MACHINE

It is a compact unit which can continuously produce various kinds of hard candies & lollipop under a strict sanitary condition.

PROFILES:

LOLLIPOP DEPOSITING MAKING MACHINE is a compact unit which can continuously produce various kinds of hard candies & lollipop under a strict sanitary condition. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.

PROCESSING CHART:

Raw material melting → Conveying → Filter → Storage → Constant syrup conveying →

Pre-heating → Micro-film vacuum cooking → Discharging → Mixing with flavor and

Color → Depositing → Cooling → De-moulding → Conveying → Packing

MAIN TECHNICAL PARAMETERS:

Capacity	150KG/H; 300KG/H
Steam Consumption	150KG/H; 300KG/H
Steam Pressure Needed	0.5-0.8MPa
Total Power	16.2KW
Depositing Speed	55N/MIN
Total Power	2KW; 3KW
Weight	1600 KG; 1800KG
Dimension	200015002100; 200018002100 MM
Machine Frame	10mm thickness A3 carbon Steel.
Shell	304 stainless steel. Thickness 1.5mm
Hopper	316 stainless steel; Thickness 1.5mm
Storage tank and pipes	316 stainless steel. Thickness 1.5mm
Total Power	7KW; 8KW
Weight	800 KG; 1000KG
Dimension	88005602200mm; 88008202200 MM
Main machine frame	A3 carbon steel. 50703 square tube
Top adopts	1.5mm stainless steel
Bottom and side adopt	Color steel heat-preservation
